CradlePoint Inc.

AER2200-1200M

Contact manufacturer
Sales
Address

1111 W Jefferson Ste 400, Boise, ID, 83702

Phone

208-908-4334

CradlePoint Inc.

AER2200-1200M

Key features
  • Internal Gigagit-class 5-CA LTE modem, with secure SIM card access and dual SIM slots
  • Includes dual-band dual-concurrent 4x4 2.4/5 GHz 802.11 a/b/g/n/ac wave 2 WiFi; 2 x 2 MIMO
  • Ten 10/100/1000 Ethernet ports (LAN/WAN configurable) and an active GPS antenna port
  • Up to 4 ports of PoE support at 802.3at power (up to120 Watts with high power AC supply)
See more
Product description

The Cradlepoint AER2200 is an advanced edge routing solution that combines cloud management, advanced security (UTM), industry leading 4G LTE failover, high-performance WiFi, and dual modem capabilities. It supports 10 ports of GigE (4 PoE enabled), and 4x4 dual-band dual-concurrent WiFi with Wave 2 ac support. The router features an 1200 Mbps LTE module* with support for Verizon LTE Bands with 5 carrier aggregation, 4x4 MIMO, 256 QAM, Ethernet support for wired networks, and WiFi as WAN.

See more
Overview
Device type
Router
Network technology
LTE & GSM
LTE category support
Cat 18
Hardware
Antenna

Battery

N/A

Display resolution

N/A

Ethernet ports

10+

SIM type

Standard/Industrial Mini SIM (2FF)

USB ports

1

Voltage supply

9~36V DC

Other features
Accelerometer
Z-Wave
Audio
Battery safety
Bluetooth
Camera
E911
eUICC
Expansion card slots
GNSS
Checked
GPS

Keyboard
Magnetic card reader
Printer
RJ11
Scanning technology
Serial
Checked
Smart card reader
Voice transmission capable
Wifi
Checked
Zigbee
Software
FOTA

Non Verizon FoTA Solution (only)

Operating System

Other


Developer Kit
EMS
MMS
Remote Management
Checked
SMS Capability
Chassis
Dimensions

8.25x7.25x1.75 in.

Weight

3 lbs

Operating Temperature

-30 °C

Storage Temperature

-30 °C

Relative Humidity

10% to 90% Non-Condensing


Rain & dust resistance
Checked
Vehicle Mounting
Checked
Network
NAT

YES

Routing Protocols

GRE, L2TP, NEMO, VRRP, STP, NHRP, OSPF, BGP, RIP, VTI, Split DNS, DNS Proxy, DNS, DHCP relay/client/server, SIP, IRC, VLAN support (802.1Q)

Security Protocol

IPSec, 802.1x (wired and wireless), TACACS+/RADIUS Authentication

VPN Support

IPSec, OpenVPN, CP Secure VPN


Fax capable
Firewall
Checked
UMTS
LTE

Band2 (1900 MHz)

Band4 (1700 MHz)

Band5 (850MHz)

Band13 (700 MHz)
