CalAmp Corp
HMU3640LB
CalAmp Corp
HMU3640LB
Key features
- Global LTE CAT 1 with 3G/2G fallback
- IP66 & IP67 Sealed
- BLE 5.2 connectivity
- Supports Modbus protocol
- Multiple I/O interfaces, including RS232/RS485, and dual CAN
Product description
The HMU-3640LB is an ideal IoT solution for industrial equipment manufacturers and asset fleet operators in construction, agriculture, mining, and more. It features shock resistance, extreme temperature support, an IP67 rating, and a durable harness for reliability in tough conditions. With upgraded Bluetooth, wired connectivity, and increased processing power, the HMU-3640LB provides essential data to reduce costs, inform critical decisions, and drive business success.
Overview
- Device type
- Vehicle Monitoring
- Network technology
- LTE Only
- LTE category support
- Cat 1
Hardware
Antenna
—
Battery
500 mAh
Display resolution
none
Ethernet ports
0
SIM type
Not Applicable
USB ports
0
Voltage supply
12/24 VDC
Other features
- Accelerometer
- Checked
- Z-Wave
- —
- Audio
- —
- Battery safety
- Checked
- Bluetooth
- Checked
- Camera
- —
- Dual SIM
- —
- E911
- —
- eUICC
- —
- Expansion card slots
- —
- GNSS
- Checked
- GPS
- Checked
- Keyboard
- —
- Magnetic card reader
- —
- Printer
- —
- RJ-11
- —
- Scanning technology
- —
- Serial
- Checked
- Smart card reader
- —
- Voice transmission capable
- —
- Wifi
- —
- Zigbee
- —
Software
FoTA For Baseband/Modem Software Update Capability
Verizon FoTA Solution and Non Verizon FoTA solution (combined)
FoTA Client Type
LWM2M
Operating System
Other
- Developer Kit
- —
- Diagnostics
- —
- Security Level
-
Security Level 1
(Regular OD devices. Minimum security requirements mandated.) - EMS
- —
- MMS
- —
- Remote Management
- Checked
- SMS Capability
- Checked
- WEA (Wireless Emergency Alert)
- —
- Persistent Prefix IPv6
- —
- Mobile Private Network
- Checked
- Fixed Wireless Access (FWA)
- —
- Network Slicing
- —
- Split Data Routing (aka Dual APN)
- —
- Multi-APN
- —
- Global Capable
- —
- Global IoT Orchestration Capable
- —
- Private Wireless Network (On Site)
- —
Chassis
Dimensions
xx
Weight
8.8 lbs
Operating Temperature
-30 °F to 75 °F
Storage Temperature
-20 °F to 25 °F
Relative Humidity
95%
- Rain & dust resistance
- —
- Vehicle Mounting
- Checked
Network
NAT
—
Routing Protocols
—
Security Protocol
—
VPN Support
—
Numbershare
N - no Numbershare
- Fax capable
- —
- Firewall
- —
- UMTS
- Checked
- LTE
-
Band4 (1700 MHz)
Band13 (700 MHz)
- LTE Global / Roaming
-
Band1 (2100MHz)
Band3 (1800MHz)
Band7 (2600 MHz)
Band8 (900 MHz)
Band12 (700 MHz)
Band14 (700 MHz)
Band17 (700 MHz)
Band18 (850 MHz)
Band20 (800 MHz)
Band25 (1900 MHz)
Band26 (850 MHz)
Band28 (700 MHz)
- GPRS
-
1800 MHz
1900 MHz
850 MHz
900 MHz
- GSM
-
1800 MHz
1900 MHz
850 MHz
900 MHz
Contact
Website
Industries
Transportation
