Ooma Inc
AirDial
Contact manufacturer
SalesAddress
525 Almanor Ave suite 200
Phone
866-343-7929
You will be redirected for purchasing information
Our development kits are currently available through third-party sites. Please choose a vendor below to be redirected for more product and purchasing information.
Vendor(s)Ooma Inc
AirDial
Key features
- Processor : Dual-core ARM Cortex A9 CPU
- Modem • Quectel EG95-NAXD • Cat-4 LTE • Data rates up to 150 Mbps down and 50 Mbps up
- Telephony • Four RJ-11 analog FXS ports • 55Vrms Low Power Ringing , LCCD converter
- Battery Backup • Replaceable battery pack 3S3P Li-ion battery: 10.95V, 3A
- Display 176x220 TFT LCD display
Product description
From schools and universities to commercial office and retail buildings, Ooma AirDial provides critical phone service to life safety phones, alarms and building entry systems.
https://www.ooma.com/business/airdial-pots-line-replacement/
Overview
- Device type
- Router with Voice Terminal
- Network technology
- LTE Only
- LTE category support
- Cat 4
Hardware
Antenna
—
Battery
Replaceable battery pack 3S3P Li-ion battery: 10.95V, 3A Capacity 85.4 Wh (7.8 Ah) provides > 8 hours of standby time
Display resolution
320x240 LCD display
Ethernet ports
2
SIM type
Standard/Industrial Micro SIM (3FF)
Compatible 3FF SIM SKUs:
For CAT M1 Devices:
- M2MTC-TRI1-NORUG-A
- M2MTC-3FF-HD-A
- M2MSIM-HD-A
- M2MTC-TRI1-NORUG-D
- M2MTC-3FF-HD-D
- M2MSIM-HD-D
- M2MTC-TRI1-NORUG-S
- M2MTC-3FF-HD-S
- M2MSIM-I
- M2MTC-HD-I
For Non CAT M1 (Cat 1, Cat 2, Cat 3, Cat 4 and above) Devices:
- M2MTRI-NONRUG-GT-A
- BULK3FF-HD-GT-A
- M2MTRI-NONRUG-GD-D
- BULK3FF-HD-GD-D
- M2MSIM-HDI-D
- M2MTRI-NONRUG-ST-S
- BULK3FF-HD-ST-S
- M2MSIM-HD-I
- M2MSIM-NR-I
eUICC GSMA Architecture Type:
M2M (GSMA SGP.02)
USB ports
1
Voltage supply
100-240 VAC 50-60Hz
Other features
- Accelerometer
- —
- Z-Wave
- —
- Audio
- —
- Battery safety
- —
- Bluetooth
- Checked
- Camera
- —
- Dual SIM
- —
- E911
- Checked
- eUICC
- Checked
- Expansion card slots
- —
- GNSS
- Checked
- GPS
- Checked
- Keyboard
- —
- Magnetic card reader
- —
- Printer
- —
- RJ-11
- Checked
- Scanning technology
- —
- Serial
- —
- Smart card reader
- —
- Voice transmission capable
- —
- Wifi
- —
- Zigbee
- —
Software
FoTA For Baseband/Modem Software Update Capability
Verizon FoTA Solution and Non Verizon FoTA solution (combined)
FoTA Client Type
LWM2M
Operating System
Linux
- Developer Kit
- —
- Diagnostics
- —
- Security Level
- —
- EMS
- —
- MMS
- —
- Remote Management
- Checked
- SMS Capability
- Checked
- WEA (Wireless Emergency Alert)
- —
- Persistent Prefix IPv6
- —
- Mobile Private Network
- Checked
- Fixed Wireless Access (FWA)
- Checked
- Split Data Routing (aka Dual APN)
- —
- Multi-APN
- —
- Global Capable
- —
- Private Wireless Network (On Site)
- —
Chassis
Dimensions
30x20x6 in.
Weight
4 lbs
Operating Temperature
0 °C to 40 °C
Storage Temperature
—
Relative Humidity
—
- Rain & dust resistance
- —
- Vehicle Mounting
- —
Network
NAT
yes , device is behind NAT
Routing Protocols
Not Applicable.
Security Protocol
Our MFVN-compliant network ensures traffic never traverses the public Internet.
VPN Support
yes, use VPN for VoIP and logging
Numbershare
N - no Numbershare
- Fax capable
- Checked
- Firewall
- —
- UMTS
- —
- LTE
-
Band2 (1900 MHz)
Band4 (1700 MHz)
Band5 (850MHz)
Band13 (700 MHz)
