Opengear
OM1208-8E-L
Contact manufacturer
SalesAddress
110 Fieldcrest Avenue, 6th Floor Edison, NJ 08837
Phone
+1 (833) 673-6432 (Sales)
Opengear
OM1208-8E-L
Key features
- AMD 4-core 64-bit x86, 4 GB RAM, 16 GB SSD internal, Trusted Platform Module chip
- 2 x USB 2.0 ports for console and storage 2 x USB 3.0 Host Ports
- 2 x 1000Base-T Ethernet/SFP Fiber port
- 8 or 4 x RJ45 RS-232 Serial plus 8 or 4 x RJ45 Gigabit Switch
- 4G LTE-A Pro cellular wireless model - Global Coverage
Product description
The Opengear OM1200 Operations Manager streamlines key actions within the NetOps workflow, as a core component of the NetOps Automation™ platform. The enhanced white box solution enables secure, automated Provisioning over LTE-A even before the production network is live, and allows the configuration and management of the remote network. With x86 64 bit architecture, it provides a secure Python runtime environment, supporting Opengear and third party NetOps Modules and out-of-band management.
Overview
- Device type
- Router
- Network technology
- LTE Only
- LTE category support
- Cat 12
Hardware
Antenna
—
Battery
—
Display resolution
—
Ethernet ports
2
SIM type
Not Applicable
USB ports
4
Voltage supply
12 VDC Universal External Supply 100-240 AC
Other features
- Accelerometer
- —
- Z-Wave
- —
- Audio
- —
- Battery safety
- —
- Bluetooth
- —
- Camera
- —
- E911
- —
- eUICC
- —
- Expansion card slots
- —
- GNSS
- —
- GPS
- Checked
- Keyboard
- —
- Magnetic card reader
- —
- Printer
- —
- RJ-11
- —
- Scanning technology
- —
- Serial
- Checked
- Smart card reader
- —
- Voice transmission capable
- —
- Wifi
- —
- Zigbee
- —
Software
FoTA For Baseband/Modem Software Update Capability
Non Verizon FoTA Solution (only)
FoTA Client Type
OMADM
Operating System
Linux
- Developer Kit
- —
- Diagnostics
- —
- Security Level
- None
- EMS
- —
- MMS
- —
- Remote Management
- —
- SMS Capability
- Checked
- WEA (Wireless Emergency Alert)
- —
- Persistent Prefix IPv6
- —
- Mobile Private Network
- Checked
- Fixed Wireless Access (FWA)
- Checked
- Split Data Routing (aka Dual APN)
- —
- Multi-APN
- —
- Global Capable
- Checked
- Private Wireless Network (On Site)
- —
Chassis
Dimensions
—
Weight
—
Operating Temperature
—
Storage Temperature
—
Relative Humidity
5% to 90% Non-condensing
- Rain & dust resistance
- —
- Vehicle Mounting
- —
Network
NAT
Linux NAT through IPTables
Routing Protocols
RIP, BGP
Security Protocol
SSH, HTTPS, SSL
VPN Support
IPsec, OpenVPN
Numbershare
N - no Numbershare
Supported Global/Roaming Markets
- Canada/Mexico
- —
- Europe
- —
- Asia
- —
- Puerto Rico/Latin America
- —
- Fax capable
- —
- Firewall
- Checked
- UMTS
- —
- LTE
-
Band2 (1900 MHz)
Band4 (1700 MHz)
Band5 (850MHz)
Band13 (700 MHz)
Band66 (1700 MHz)
