Pepwave Limited

MAX-BR1-MINI-LTE-US

New
Contact manufacturer
Sales
Address

sales@peplink.com

Phone

650-450-9668

Pepwave Limited

MAX-BR1-MINI-LTE-US

Key features
  • Affordable Cellular Router for Large-Scale Deployments
  • Add-On M2M Capability, Multiple Power Input Options
  • Fast Setup & Capable Cloud Management for Fleet Tracking and Management
  • Customizable Captive Portal
  • Rugged 4G LTE Redundant SIM Router with Failover License Available
See more
Product description

The BR1 Mini offers redundant SIM slots with automatic switching, DC or terminal block power capability, advanced GPS fleet tracking, and remote management, all packed into a durable metal enclosure. The failover software license is available for BR1-MINI that enables Ethernet and Wi-Fi WAN.

See more
Overview
Device type
Router
Network technology
LTE & GSM
LTE category support
Cat 4
Hardware
Antenna

Battery

NA

Display resolution

NA

Ethernet ports

3

Dual SIM type

Standard/Industrial Mini SIM (2FF)

Compatible 2FF SIM SKUs:

For CAT M1 Devices:

  • M2MTC-TRI1-NORUG-A
  • M2MTC-2FF-HD-A
  • M2MSIM-HD-A
  • M2MTC-TRI1-NORUG-D
  • M2MTC-2FF-HD-D
  • M2MTC-TRI1-NORUG-S
  • M2MTC-2FF-HD-S

For Non CAT-M1 (Cat 1, Cat 2, Cat 3, Cat 4, and above) Devices:

  • M2MTRI-NONRUG-GT-A
  • BULK2FF-HD-GT-A
  • M2MTRI-NONRUG-GD-D
  • BULK2FF-HD-GD-D
  • M2MTRI-NONRUG-ST-S
  • BULK2FF-HD-ST-S
  • M2MSIM-HD-I
  • M2MSIM-NR-I







Standard/Industrial Mini SIM (2FF)

Compatible 2FF SIM SKUs:

For CAT M1 Devices:

  • M2MTC-TRI1-NORUG-A
  • M2MTC-2FF-HD-A
  • M2MSIM-HD-A
  • M2MTC-TRI1-NORUG-D
  • M2MTC-2FF-HD-D
  • M2MTC-TRI1-NORUG-S
  • M2MTC-2FF-HD-S

For Non CAT-M1 (Cat 1, Cat 2, Cat 3, Cat 4, and above) Devices:

  • M2MTRI-NONRUG-GT-A
  • BULK2FF-HD-GT-A
  • M2MTRI-NONRUG-GD-D
  • BULK2FF-HD-GD-D
  • M2MTRI-NONRUG-ST-S
  • BULK2FF-HD-ST-S
  • M2MSIM-HD-I
  • M2MSIM-NR-I







USB ports

0

Voltage supply

12W (max.)

Other features
Accelerometer
Z-Wave
Audio
Battery safety
Bluetooth
Camera
E911
eUICC
Expansion card slots
GNSS
Checked
GPS
Checked

Keyboard
Magnetic card reader
Printer
RJ11
Scanning technology
Serial
Smart card reader
Voice transmission capable
Wifi
Checked
Zigbee
Software
FoTA For Baseband/Modem Software Update Capability

Verizon FoTA Solution and Non Verizon FoTA solution (combined)

Operating System

Linux


Developer Kit
Security Level
None
EMS
MMS
Remote Management
Checked
SMS Capability
WEA (Wireless Emergency Alert)
Chassis
Dimensions

4.1x4.3x1.2 in.

Weight

0.77 lbs

Operating Temperature

-40 °F to 149 °F

Storage Temperature

-40 °F to 149 °F

Relative Humidity

15% – 95% (non-condensing)


Rain & dust resistance
Vehicle Mounting
Checked
Network
NAT

One-to-one, one-to-many

Routing Protocols

Static, Dynamic, OSPF, RIPv2, BGP

Security Protocol

Yes

VPN Support

PepVPN, IPSec, L2TP

Numbershare

No Numbershare


Fax capable
Firewall
Checked
UMTS
Checked
LTE

Band66 (1700 MHz)

Band2 (1900 MHz)

Band4 (1700 MHz)

Band5 (850MHz)

Band13 (700 MHz)
