Fibocom Wireless Inc.
FM350-GL-16
Fibocom Wireless Inc.
FM350-GL-16
Key features
- • Dual SIM (one built-in eSIM), 1.8V/3V • Bodysar supported
- Low power and low cost. Globally approval module
Product description
1. Small ,Slim M.2 form factor
2. High speed data module , Cat19 LTE
• LTE: DL 1.0Gbps (CAT16)/UL 211Mbps (CAT18)
3. Rx diversity for 3G/4G/
4. 2 ANT supported
5. Low power and low cost
6. Globally approval module
Overview
- Network technology
- LTE + Global Bands
- LTE category support
- Cat 19
- Form factor
- M.2
Hardware & Network
Features
- UDP
- Checked
- TCP
- Checked
- UART
- —
- GPIO
- —
- Serial
- —
- GPS
- Standalone
- LTE
-
Band2 (1900 MHz)
Band4 (1700 MHz)
Band5 (850MHz)
Band13 (700 MHz)
Band48 (3500 MHz)
Band66 (1700 MHz)
- LTE Global / Roaming
-
Band1 (2100MHz)
Band3 (1800MHz)
Band7 (2600 MHz)
Band12 (700 MHz)
Band14 (700 MHz)
Band40 (2300 MHz)
Supported Global/Roaming Markets
- Canada/Mexico
- —
- Europe
- —
- Asia
- —
- Puerto Rico/Latin America
- —
Software
FCC ID
null
FoTA For Baseband/Modem Software Update Capability
Verizon FoTA Solution and Non Verizon FoTA solution (combined)
FoTA Client Type
LWM2M
Other features
- Voice capable
- —
- Native IM client
- —
- Battery safety
- —
- SMS Capability
- Checked
- Developer Kit
- Checked
- ALO (Airborne LTE Operations)
- —
- Diagnostics
- —
- Global Capable
- Checked
- eUICC
- —
- Private Wireless Network (On Site)
-
Checked
- Network Slicing
- —
- Mobile Private Network
- Checked
Chassis & power source
Dimensions
3.0x5.2x0.23 in.
Relative humidity
5% - 90%
Stored temperature
-40°C °C to +85°C °C
Operating temperature
-30 °C to +75 °C
Weight
0.282 oz
Voltage supply
DC 3.135V～4.4V, Typical 3.3V
Power consumption
<11.55w
