Sierra Wireless
EM7690
Contact manufacturer
SalesSierra Wireless
EM7690
Key features
- Air Interface: 4G LTE and UMTS
- Hardware Supported Connections: PCIe-3 and USB3
- GPS (assisted or standalone): Both Assisted, Standalone
- Operating System: Qualcomm SDX55 SnapDragon OS
Product description
Sierra Wireless EM7690 Embedded Module supports 4G LTE advanced Pro, 3G (HSPA , UMTS), and GNSS connectivity for a wide range of devices and purposes, including business, personal, and portable computing and communication devices, IoT devices, M2M applications and industrial use cases.
Overview
- Network technology
- LTE + Global Bands
- LTE category support
- Cat 20
- Form factor
- M.2
Hardware & Network
Features
- UDP
- —
- TCP
- Checked
- UART
- —
- GPIO
- Checked
- Serial
- —
- GPS
- Standalone
- LTE
-
Band2 (1900 MHz)
Band4 (1700 MHz)
Band5 (850MHz)
Band13 (700 MHz)
Band48 (3500 MHz)
Band66 (1700 MHz)
Software
FCC ID
N7NEM76
FoTA For Baseband/Modem Software Update Capability
Verizon FoTA Solution (only)
FoTA Client Type
LWM2M
Other features
- Voice capable
- —
- Native IM client
- Checked
- Battery safety
- —
- SMS Capability
- Checked
- Developer Kit
- Checked
- ALO (Airborne LTE Operations)
- —
- Diagnostics
- Checked
- Global Capable
- —
- eUICC
- —
- Private Wireless Network (On Site)
-
Checked
LTE Licensed
LTE CBRS
5G Licensed - Network Slicing
- —
- Mobile Private Network
- Checked
Chassis & power source
Dimensions
5.2x3.0x.25 in
Relative humidity
85%
Stored temperature
-40 °C to 85 °C
Operating temperature
-30 °C to 70 °C
Weight
3.0 lbs
Voltage supply
—
Power consumption
—
