Rolling Wireless
AR7592
Rolling Wireless
AR7592
Key features
- Automotive-grade manufacturing (TS-16949 certified). Automotive quality processes (PPAP, 8D, PCN, FA, …).
- Multicore Architecture: ARM Cortex-A7 (1.2GHz) application core dedicated to customer.
- Advanced voice quality with AEC/NR according VDA.
- Management Service via AirVantage® M2M Cloud.
- GNSS (GPS, Glonass, Galileo, BeiDou, QZSS)
Product description
The AR7592-1 CAT6 module is designed for the automotive industry. The AR7592-1 supports LTE, WCDMA and GSM air interface standards. Global Navigation Satellite System (GNSS) capabilities including GPS, GLONASS, Galileo, BeiDou, and QZSS.
Overview
- Network technology
- LTE + Global Bands
- LTE category support
- Cat 6
- Form factor
- Surface Mount / Soldered
Hardware & Network
Features
- UDP
- —
- TCP
- —
- UART
- Checked
- GPIO
- Checked
- Serial
- —
- GPS
- Standalone
- LTE
-
Band2 (1900 MHz)
Band4 (1700 MHz)
Band5 (850MHz)
Band13 (700 MHz)
- LTE Global / Roaming
-
Band12 (700 MHz)
- GPRS
-
850 MHz
- GSM
-
850 MHz
Software
FCC ID
2AX2UAR7592V1
FoTA For Baseband/Modem Software Update Capability
Non Verizon FoTA Solution (only)
FoTA Client Type
OMADM
Other features
- Voice capable
- —
- Native IM client
- Checked
- Battery safety
- Checked
- SMS Capability
- Checked
- Developer Kit
- Checked
- ALO (Airborne LTE Operations)
- —
- Diagnostics
- —
- Global Capable
- —
- eUICC
- —
- Private Wireless Network (On Site)
- —
- Network Slicing
- —
- Mobile Private Network
- Checked
Chassis & power source
Dimensions
3.2x3.7x.36 in.
Relative humidity
95% or less
Stored temperature
-40 °C to 85 °C
Operating temperature
–40 °C to 85 °C
Weight
10 g
Voltage supply
—
Power consumption
2 Amps
